K4V220-08 K4V230C-08 K4V330C-08 K4V330E-08 K4V330P-08 K4V230P-08电磁换向阀气动换向阀电磁阀

K4V220-08 K4V230C-08 K4V330C-08 K4V330E-08 K4V330P-08 K4V230P-08电磁换向阀

马上询价

Model	4V210-06	4V220-06	4V230C-06	4V230E-06	4V230P-06	4V210-08	4V220-08	4V230C-08	4V230E-08	4V230P-08
	4A210-06	4A220-06	4A230C-06	4A230E-06	4A230P-06	4A210-08	4A220-08	4A230C-08	4A230E-08	4A230P-08
Position and way NO.	5/2 way		5/3Five-way			5/2 way		5/3 way
Effective area	14mm2(CV=0.78)		12mm2(CV=0.67)			16mm2(CV=0.89)		12mm2(CV=0.67)
Model	3V210-06		3V220-06	3A210-06	3A220-06	3V210-08		3V220-08	3A210-08	3A220-08
Position and way NO.	3/2 way					3/2 way
Effective area	14mm2(CV=0.78)					16mm2(CV=0.89)
Port size	Air inlet=Air outlet=Exhaust=G1/8″					Air inlet=Air outlet=G1/4″ Exhaust=G1/8″
Fluid	40 micron fi ltered air
Operation	Inside pilot type
Operating pressure	0.15~0.8MPa
Max. proof pressure	1.2MPa
Temperature	5~50^oC
Allowable voltage	±10% of rated voltage
Power consumption	AAC: 4.5VA DC: 3W
Coil insulation & protection grade	Class F.IP65
Electrical entry	Lead wire or connector
Highest action frequency	5 cycle/second
Shortest excitation time	0.05 second
